System

Operating Instructions

Single Scanner Input Operations

When operating the system using two headsets and a single scanner (input)

the toggle switch (see photo below) must be in the UP position(All) on BOTH

HEADSETS.

Two Scanner Input Operations

When operating the system using two headsets with a scanner plugged into

each headset you must have the toggle switch on BOTH HEADSETS set to

the DOWN position. (see photo below)

Intercom System Power

Inside the right ear cup of each headset is a 9-Volt battery that powers the

system. We always recommend that you always have a spare battery for

each headset on hand. We also recommend using alkaline batteries.

Cables - 3-Pin Umbilical Cable

You should route the cables where they are the most convenient for your

seating arrangement(these cables can plug into either side of the headset).

Arrangements for multiple headsets and inputs are provided inside

this guide.

Volume ControlsInput Toggle Switch

Headset Volume

DOWN

Isolate

UP - ALL

quieter

louder

Mic Volume

* More instructions on back of pamphlet

1 2 3
